相机制造商

传感器
产品型号 类型 彩色C/ 扫描类型 图像格式/分 工作波段 接口 帧率 数据率
Scan
Spectrum
辨率
Product Sensor 黑白M type Image format digitized Interface Frame/s Data rate
type
Hangzhou Hikrobot Technology Co Ltd Hangzhou, China; 86-571-8764-5928; www.hikrobotics.com; hikrobotics@hikvision.com
X86 Smart Camera CMOS M Area array — IR, NIR Digital I/O, GigE, RS-232, USB 1.0/2.0 25-80 1 Gbps
Movidius VPU Platform Smart CMOS M Area array — IR, NIR Digital I/O, GigE, RS-232 40-120 1 Gbps
Camera
Hitachi Kokusai Electric America Ltd Woodbury, NY, USA; 817-379-5013; www.hitachikokusai.com/ivs; phyllis.vela@hitachikokusai.com
HV-D30 CCD C Area array 768 x 494 x 3 VIS Analog, NTSC, PAL, RGB, S-Video 30 —
KP-F510UB, KP-FD510UB CCD C+M Area array 2456 x 2058 VIS USB3 18 —
1600 x 1200
HV-F202GV, HV-F202SCL CCD C Area array VIS Camera Link, GigE 30 —
x 3
HV-HD33 CMOS C Area array 1280 x 720 x 3 VIS Analog, HD-SDI 60 —
KP-D20A, KP-D20B CCD C Area array 768 x 494 VIS Analog, S-Video 30 —
KP-HD20A CMOS C Area array 1944 x 1092 VIS HD-SDI 30 —
KP-F230SCL, KP-F202GV CCD M Area array 1628 x 1236 VIS Camera Link, GigE 30 —
KP-F31SCL, KP-F33GV CCD M Area array 659 x 494 VIS Camera Link, GigE 120 —
KP-F500SCL, KP-F500GV CCD M Area array 2456 x 2058 VIS Camera Link, GigE 16 —
KP-F145GV CCD M Area array 1392 x 1040 NIR, VIS GigE 30 —
Hitachi Kokusai Electric Europe GmbH Neu Isenburg, Germany; 49-6102-8332-0; www.hitachi-keu.com; info@hitachi-keu.com
HV-F202 Series CCD C Area array — VIS Camera Link, GigE, RGB 30 —
HV-F130 Series CCD C Area array SXGA VIS GigE, RGB 30 —
HV-F32 Series CCD C Area array VGA VIS GigE, RGB ≤200 —
KP-FM400WCL/KP-FMR400WCL CMOS C+M Area array — VIS — 150 —
KP-FM200WCL/KP-FMR200WCL CMOS C+M Area array — VIS — 280 —
KP-FXXXSCL CCD M Area array — IR, VIS Camera Link 15–120 —
KP-FDXXXSCL CCD C Area array — VIS Camera Link, RGB 12–30 —
KP-FM(D)200UB CMOS C+M Area array — NIR, VIS Camera Link, GigE, USB3 125 —
50 (1080i),
KP-HD20A-(S2) CMOS C Area array 1920 x 1080 — HD-SDI, HDTV —
25 (1080p)
IDS Imaging Development Systems GmbH Obersulm, Germany; 49-7134-96196-0; www.ids-imaging.com; info@ids-imaging.com
800 x 600–
GigE uEye SE camera family CMOS C+M Area array NIR, VIS Digital I/O, GigE ≤205 —
4104 x 3006
2456 x 2054–
uEye SE USB 3.1 Gen 1 CMOS C+M Area array VIS Digital I/O, USB3 — —
4104 x 3006
808 x 608–
uEye LE USB 3.1 Gen 1 CMOS C+M Area array VIS Digital I/O, USB3 ≤135 —
3088 x 2076
800 x 600–
GigE uEye FA camera family CMOS C+M Area array VIS Digital I/O, GigE ≤205 —
2448 x 2048
752 x 480–
GigE uEye CP Rev. 2 CMOS C+M Area array NIR, VIS Digital I/O, GigE ≤205 —
3088 x 2076
752 x 480–
USB 3 uEye CP camera family CMOS C+M Area array NIR, VIS Digital I/O, USB3 ≤575 —
4912 x 3684
Ensenso X camera family CMOS M Area array 1280 x 1024 VIS Digital I/O, GigE 5 —
752 x 480–
Ensenso N camera family CMOS M Area array VIS Digital I/O, GigE, USB 1.0/2.0 — —
1280 x 1024
1280 x 1024–
GigE uEye LE camera family CMOS C+M Area array NIR, VIS Digital I/O, GigE ≤50 —
2560 x 1920
1280 x 1024–
USB 3 uEye LE camera family CMOS C+M Area array NIR, VIS Digital I/O, USB3 ≤60 —
4912 x 3684
1 (full),
USB 3 uEye XC camera CMOS C Area array 4192 x 3104 VIS USB3 —
30 (video)
USB 2 uEye XS camera family CMOS C Area array 2592 x 1944 VIS USB 1.0/2.0 15 —
1280 x 1024–
USB 3 uEye ML camera family CMOS C+M Area array NIR, VIS Digital I/O, USB3 ≤60 —
2560 x 1920
752 x 480–
USB 2 uEye SE camera family CMOS C+M Area array NIR, VIS Digital I/O, USB 1.0/2.0 ≤87 —
3840 x 2748
