Sensor Color/ Spectrum
Product Scan type Image format Interface Frame/s Data rate
type Mono digitized
Photron USA Inc San Diego, CA, USA; 858-684-3555; www.photron.com; image@photron.com
FASTCAM Mini WX50 High Speed CMOS C+M Area array 2048 x 2048 VIS GigE 60–67,000 —
Camera
FASTCAM Mini WX100 CMOS C+M Area array 2048 x 2048 VIS GigE 60–80,000 —
FASTCAM Mini AX50 High Speed CMOS C+M Area array 1024 x 1024 VIS GigE 60–170,000 —
Camera
FASTCAM Mini AX100 CMOS C+M Area array 1024 x 1024 VIS GigE 60–540,000 —
FASTCAM Mini AX200 High Speed CMOS C+M Area array 1024 x 1024 VIS GigE 60–900,000 —
Camera
FASTCAM Multi CMOS C+M Area array 1280 x 1024 VIS Ethernet 60–750,000 —
PhotoCam Speeder V2 CMOS C+M Area array 512 x 512 VIS Proprietary 60–100,000 —
FASTCAM SA-Z CMOS C+M Area array 1024 x 1024 VIS GigE 60–2,100,000 —
Digital I/O, GigE, HD-SDI, NTSC/PAL/
FASTCAM SA-X2 CMOS C+M Area array 1024 x 1024 VIS 60–1,000,000 —
RS-170
FASTCAM SA1.1 CMOS C+M Area array 1024 x 1024 VIS GigE, NTSC/PAL/RS-170, RS-422/LVDS 675,000 —
FASTCAM SA2 CMOS C+M Area array 2048 x 2048 VIS GigE, RS-422/LVDS 60–86,400 —
FASTCAM SA4 CMOS C+M Area array 1024 x 1024 VIS GigE, RS-232, RS-170, RS-422/LVDS 60–500,000 —
FASTCAM SA5 CMOS C+M Area array 1024 x 1024 VIS GigE, RS-232, RS-170, RS-422/LVDS 60–1,550,000 —
Fastcam SA6 CMOS C+M Area array 1920 x 1440 VIS GigE 60–75,000 —
FASTCAM MC2 CMOS C+M Area array 512 x 512 VIS GigE, NTSC/PAL/RS-170 60–10,000 —
FASTCAM MH4 -10K CMOS C+M Area array 512 x 512 VIS GigE 60–10,000 —
PixeLINK Ottawa, ON, Canada; 613-247-1211; www.pixelink.com; sales@pixelink.com
PL-D721 USB 3.0 Camera CMOS C+M Area array — NIR, VIS USB3 150 —
PL-D722 USB 3.0 Camera CMOS C+M Area array — NIR, VIS USB3 87 —
PL-D725 USB 3.0 Camera CMOS C+M Area array — NIR, VIS USB3 70 —
PL-D775 USB 3.0 Camera CMOS C Area array — NIR, VIS USB3 15 —
